XA125/20、XA125/20A、XA125/26、XA125/26A、XA125/26B、XA125/32、XA125/32A、XA125/32B、XA125/40、XA125/40A、XA125/40B
上海邦泉泵業(yè)制造有限公司 咨詢熱線：021-57648032
性能表PERFORMANCE TABLE n=2900rpm
|
型號 Model |
流量 Capacity Q |
揚程 Head H (m) |
轉(zhuǎn)速 Speed n (rpm) |
功率 Power P (kW) |
電機型號 Motor supplied (kW) |
泵效率 Eff. л (%) |
必需汽蝕余量 (NPSH)r (m) |
葉輪直徑 lmpeller diameter (mm) |
泵口徑 Pump nozzle (mm) |
錐管直徑 Tape pipe diameter (mm) |
重量 Weight (kg) |
||||
|
m3/h |
L/s |
軸 Shaft |
電機 Motor |
ln |
Out |
ln |
Out |
||||||||
|
XA125/20 |
237.6 360 475 |
66 100 132 |
54.5 49 40 |
2900 |
59.3 66.3 70.9 |
75 90 90 |
Y280M-2 90kW |
59.5 72.5 73 |
7 7.2 7 |
Φ214 |
150 |
125 |
250 |
200 |
106 |
|
XA125/20A |
228 345 455 |
63.2 95.8 126 |
49.5 44 35.3 |
2900 |
53 58 61 |
75 75 75 |
Y280S-2 75kW |
58.5 71.5 72 |
7 7.1 6.85 |
Φ205 |
150 |
125 |
250 |
200 |
106 |
性能表PERFORMANCE TABLE n=1450rpm
|
型號 Model |
流量 Capacity Q |
揚程 Head H (m) |
轉(zhuǎn)速 Speed n (rpm) |
功率 Power P (kW) |
電機型號 Motor supplied (kW) |
泵效率 Eff. л (%) |
必需汽蝕余量 (NPSH)r (m) |
葉輪直徑 lmpeller diameter (mm) |
泵口徑 Pump nozzle (mm) |
錐管直徑 Tape pipe diameter (mm) |
重量 Weight (kg) |
||||
|
m3/h |
L/s |
軸 Shaft |
電機 Motor |
ln |
Out |
ln |
Out |
||||||||
|
XA125/20 |
115 190 230 |
32 53 63.6 |
14.2 12.5 11 |
1450 |
7.3 8.55 9.03 |
11 11 11 |
Y160M-4 11kW |
61 76 76 |
2.6 3.5 3 |
Φ214 |
150 |
125 |
200 |
150 |
106 |
|
XA125/26 |
144 240 288 |
40 66.67 80 |
23.5 21 18.8 |
1450 |
13.17 16.95 18.9 |
18.5 22 22 |
Y180L-4 22kW |
70 81 78 |
2.3 2.5 3.2 |
Φ264 |
150 |
125 |
200 |
150 |
115 |
|
XA125/26A |
139 232 278.5 |
38.61 64.44 77.36 |
21.3 19.2 17 |
1450 |
12.03 15.35 16.96 |
15 22 22 |
Y180L-4 22kW |
67 79 76 |
2.3 2.5 3 |
Φ255 |
150 |
125 |
200 |
150 |
115 |
|
XA125/26B |
134 223 267.5 |
37.22 61.94 74.31 |
19.7 17.5 15.7 |
1450 |
11.23 13.98 15.46 |
15 18.5 18.5 |
Y180M-4 18.5kW |
64 76 74 |
2.3 2.4 2.8 |
Φ245 |
150 |
125 |
200 |
150 |
115 |
|
XA125/32 |
120 200 240 |
33.3 55.6 66.7 |
35.1 32 29.5 |
1450 |
17.36 22.35 24.72 |
22 30 30 |
Y200L-4 30kW |
66 78 78 |
2.1 2 2.7 |
Φ329 |
150 |
125 |
200 |
150 |
163 |
|
XA125/32A |
115 191 229 |
31.94 53.06 63.61 |
31.5 29 26.5 |
1450 |
15.78 20.11 22.2 |
18.5 30 30 |
Y200L-4 30kW |
62.5 75 74.5 |
2.15 1.95 2.4 |
Φ315 |
150 |
125 |
200 |
150 |
163 |
|
XA125/32B |
109 182 218.5 |
30.28 50.56 60.7 |
28.5 26 24 |
1450 |
14.1 17.77 19.7 |
18.5 22 22 |
Y180L-4 22kW |
60 72.5 72.5 |
2.2 2 2.2 |
Φ300 |
150 |
125 |
200 |
150 |
163 |
|
XA125/40 |
144 245 300 |
40 68.05 83.33 |
58 52 46 |
1450 |
34.46 46.65 52.2 |
45 55 75 |
Y280S-4 75kW |
66 76 72 |
2.2 2.4 3.2 |
Φ409 |
150 |
125 |
200 |
150 |
181 |
|
XA125/40A |
139 236.5 289 |
38.61 65.7 80.42 |
53.5 48 42.5 |
1450 |
31.4 41.78 47.87 |
37 55 55 |
Y250M-4 55kW |
64.5 74 70 |
2.2 2.4 3 |
Φ395 |
150 |
125 |
200 |
150 |
181 |
|
XA125/40B |
133.5 227.5 278.5 |
37.08 63.2 77.36 |
49.5 44 39 |
1450 |
28.56 37.6 43.18 |
37 45 55 |
Y250M-4 55kW |
63 72.5 68.5 |
2.2 2.3 2.8 |
Φ380 |
150 |
125 |
200 |
150 |
181 |
